SAC3500 Sany Second Hand Truck Cranes 350 Ton Mobile Crane 112m

  • SAC3500 Sany Second Hand Truck Cranes 350 Ton Mobile Crane 112m
  • SAC3500 Sany Second Hand Truck Cranes 350 Ton Mobile Crane 112m
Place of Origin China
Brand Name Sany
Certification CE,ISO9001
Model Number SAC3500
Minimum Order Quantity 1
Price Negotiable
Packaging Details Bulk
Delivery Time 5-7 Days
Payment Terms L/C, T/T

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Condition Used Maximum Lifting Height 15.2 - 112m
Maximum Lifting Weight 350ton Axle Number 6
Jib 2 Section  production Date 2014
High Light

SAC3500 Second Hand Truck Cranes

,

112m Second Hand Truck Cranes

,

350 ton mobile crane
Leave a Message
Product Description

Used Truck Crane Sany SAC3500 Second Hand Truck Mobile Crane



Production Details:



Model NO.



SAC3500

 Boom Type Telescopic



Max. Rated Lifting Capacity



 350000 kg Max. Lifting Height of Jib 70m



Max Gradeability



 49% Working Diameter 24m



Transport Package



 Complies with Min. export packaging requirements Specification

18035×3000×4000mm



Driving mileage



 820000Km Working hours 8600h



Trademark



 Sany Place of Origin China



HS Code



   Supply Capacity 10 Units Per Month



  • Sany SAC3500 engine, transmission, tires and other main parts are all well-known brands, with strong power, which can meet the driving needs of various road conditions;
  • Innovative 6-axle chassis design, one-, three-, five- and six-axle drive, full-axle steering, easy manipulation, flexible steering, and better maneuverability;
  • The driving dual-circuit braking system is adopted for safer braking; at the same time, multiple braking modes make the braking performance more reliable;
  • Fully optimized 6-section elliptical main boom makes the boom more uniform, lighter in weight and higher in safety;
  • Equipped with a Y-type super-lifting device, the lifting performance of the long boom section is more than doubled, and it can be installed without an auxiliary crane;
  • Equipped with a variety of combined variable balance weights, it can meet the needs of different working conditions and maximize the performance of structural parts.



Product Parameters:

Dimensions

Overall length: 18035mm

Overall width: 3000mm

Overall height: 4000mm
Dynamic parameters

Rated power of the engine on operating cab: 205/2200kw/(r/min)

Rated torque of the engine on operating cab: 1100/1400N.m/(r/min)

Rated power of the engine on driving cab: 440/1800kw/(r/min)

Rated torque of the engine on driving cab: 2800/1300N.m/(r/min)
Traveling parameters

Max. traveling speed: 80Km/h

Min. turning diameter: ≤ 24m

Max. grade: 49%

Braking distance (vehicle speed is 30km/h): ≤ 10m
Performance parameters

Max. lifting moment: basic arm 11520kN.m

Boom length: main boom 15.2～70m

Boom length: fixed jib 6～42m

Boom length: luffing jib 12～78m
Working speed

Main hoisting mechanism single rope hoisting speed (no-load fourth floor): 130m/min

Boom full extension/retraction time: ≥533s

Max. rotation speed: ≤1.2r/min
