Sany STC Used Truck Crane 80 Ton Second Hand Crane 65m

Place of Origin China
Brand Name Sany
Certification CE , ISO9001
Model Number STC80
Minimum Order Quantity 1
Price Negotiable
Packaging Details Bulk
Delivery Time 5-7 Days
Payment Terms L/C, T/T

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571


If you have any concern, we provide 24-hour online help.

Product Details
Status Used Max. Lifting Height 12.9 - 65m
Max. Lifting Weight 80 Ton Axle No. 4
Jib Boom 2 Section Production Date 2019
High Light

Sany STC Used Truck Crane


65m Used Truck Crane


80 Ton Second Hand Crane

Leave a Message
Product Description

Used Sany Truck Crane Zoomlion STC80 Ton Second Hand Crane


Production Details:


Model No.


STC80 Boom Type Telescopic


Max. Rated Lifting Capacity


80000 kg Max. Lifting Height of Jib 50m


Max Gradeability


44% Working Diameter 24m


Transport Package


Complies with Min. export packaging requirements Specification 15290mm×2400mm×3210mm


Driving Mileage


120000km Working hours 12000h




SANY Place of Origin China


HS Code


  Supply Capacity

10 Units/ Month


1. High energy efficiency--new 80 tons truck crane

  • Five section U-shaped main boom with large cross-section, the full length of the boom is 50meters;
  • 8m lateral outrigger range, full counterweight 15.65ton, excellent lifting performance.
  • Brand new 2.8meters wide chassis, heightened and widened rectangular section frame, enhanced torsional and bending resistance of hoisting load;
  • The maximum grade is 44%, and the fuel consumption per 100km is 44L.


2. High-efficiency and energy-saving hydraulic system

  • Brand oil pump, hoisting motor configuration, to match with the precision hoisting: the minimum stable speed of rotation is 0.1°/s, and the minimum stable speed of hoisting is 1.5m/min;
  • Compared with the hydraulic control system, the electronic control system saves 15% of the overall energy saving when hoisting on the vehicle, and the heavy-load operation efficiency increases by 30%;


3. Comfortable and safe operating experience

  • The 0-20° tiltable and widened control room makes working at heights more comfortable and safer;
  • Counterweight remote control operation, mechanical structure mounting, no need to unload for short-distance transportation, safe and reliable;
  • The boarding shed is simplified, make it more convenient on using and maintenance.


Product Parameters:

Overall length 15290mm
Overall width 2800mm
Overall height 3880mm
Engine max. power 276/1900Kw/rpm
Engine max. output torque 1800/1000-1400N.m/rpm
Top speed 80Km/h
Min. turning radius 12m
Approach angle ≥10°
Departure angle ≥14°
Max. grade 44%
Fuel consumption per 100 km ≤44L
Max. Rated Gross Lifting Weight 80t
Turntable tail turning radius 4.385m
Max. Lifting Moment - Basic Arm 3293kN.m
Max. Lifting Moment - Longest Main Boom 1803kN.m
Outrigger span (horizontal × vertical) 8×6.43m
Boom Length - Basic Boom 12.96m
Boom Length - Longest Main Boom 50m
Boom length - longest main boom + jib 67.5m

Max. hoist rope speed (Main winch)

(no load)

Max. hoist rope speed (Auxiliary winch) (no load) 130m/min
Boom full extension/retraction time 140s/160s
Boom full up/down time 65s/90s
Swing speed 0 ~ 1.8r/min
The total mass of the whole machine 50000
Axle load - one and two axle loads 24000kg
Axle load - three and four axle loads 26000kg
