25ton Second Hand Truck Cranes Sany STC250C5-1 Second Hand Truck Mobile Crane

Place of Origin China
Brand Name Sany
Certification CE,ISO9001
Model Number STC250C5-1
Minimum Order Quantity 1
Price Negotiable
Packaging Details Bulk
Delivery Time 5-7 Days
Payment Terms L/C, T/T

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

Product Details
Condition Used Maximum Lifting Height 13 - 51m
Maximum Lifting Weight 25ton Axle Number 3
Jib 2 Section  production Date 2020
High Light

25ton Second Hand Truck Cranes


Sany Second Hand Truck Cranes



Leave a Message
Product Description

Used Truck Crane Sany STC250C5-1 Second Hand Truck Mobile Crane


Production Details:


Model NO.


STC250C5-1 Boom Type Telescopic


Max. Rated Lifting Capacity


25000 kg Max. Lifting Height of Jib 51m


Max Gradeability


30% Working Diameter 24m


Transport Package


Complies with Min. export packaging requirements Specification 113000×2550×3590mm


Driving mileage


1200Km Working hours 1000h




Sany Place of Origin China


HS Code


84262000 Supply Capacity 10 Units Per Month


Arm length and long performance

■ Five-section large-section U-shaped main boom with a full extension of 42.5 meters, leading the industry and covering a wide range of operations;

■ Single-plate boom head and compact boom tail, the lap length between booms is industry-leading, and the load-carrying capacity is strong. The boom is designed with an upturned design and the deflection of the lifting load is small.


High load carrying capacity chassis

■ Brand new 2.55m wide chassis, heightened and widened rectangular frame with variable section, comprehensively enhanced hoisting, torsion and bending capacity;

■ Adopt Shangchai high-horsepower engine, Fast 9-speed gearbox with synchronizer, the Max. grade is 42%. Dual variable pump intelligent flow distribution hydraulic system;

■ Load-sensing system: high-flow double variable piston pump, sufficient flow but no waste, efficient operation, energy saving and environmental protection;

■ Intelligent flow distribution: Using the new intelligent flow distribution main valve, the amplitude of the combined action is independent, and it is not disturbed by other actions, which greatly improves the controllability of the combined action. Using post-valve compensation technology, the flow is distributed on demand, the Min. stable speed of the hoisting single rope is 1.98m/min, and the Min. stable rotation speed is 0.18°/s, which can achieve mm-level accurate hoisting;

■ Power management: new power matching and power control, reduce engine speed under working conditions, save energy and reduce noise;

■ Integrated swing buffer control: Integrating boost buffer, sequential braking and free-slip technology, swing start and stop is soft and stable.


Intelligent control system

■ Intelligent energy-saving system: intelligent energy-saving mode, energy-saving and powerful modes, reduce fuel consumption under operating conditions, leading the industry;

■ Intelligent bus network system: vehicle controller, display, display instrument, I/O module, main sensor, etc. adopt CAN bus network, high-speed information transmission and response speed less than 20ms;

■ Intelligent fault diagnosis system: The operating device is equipped with an intelligent controller, and the body is equipped with a BCM control module. It has a fault diagnosis system, which can accurately locate the fault point and facilitate maintenance;

■ Intelligent power distribution and control: dedicated battery compartment, intelligent distribution and control of vehicle power;

■ 7' color display + intelligent panel + intelligent IO power distribution module: high-definition large-screen display, silicone panel control, further improve ergonomics;

■ Precise force limit system and safety protection: Sany's self-proprietary torque limiter system has comprehensive safety protections such as overload, over-discharge, over-roll, etc.; separate two-section boom length measurement, boom length optional, flexible and safe and reliable operation .


This equipment was manufactured in 2020. It has traveled more than 1,000 kilometers and has worked for more than 800 hours. It is 90% new. The weight of the vehicle is 34T. Shangchai SC9DF300.1Q5 (National V), no big repairs, no malfunction, regular maintenance, complete accessories, and excellent performance at present.


Product Parameters:

Performance parameters
Max. lift height 51m
Max. Lifting Moment 1158kN:m
Max. lifting weight 25t
Speed parameter
Main hoist Max. single rope speed 135m/min
Boom full extension/retraction time 100/100s
Boom full up/down time 38/45s
Max. rotation speed 2.5r/min
Weight parameter
Total weight of the whole machine 34000kg
Max. weight 3.34t
Overall length of the machine 13000mm
Overall width of the machine 2550mm
Overall height of the machine 3590mm
Outrigger span (horizontal x vertical) 6.4x5.4m
Dynamic parameters
Engine Max. power 221/2200kW/rpm
Engine Max. output torque 1250N·m/(1300-1500)/rpm
Engine model Shangchai SC9DF300.1Q5 (Euro V)
Traveling parameters
Top speed 90km/h
Min. turning radius 10.5m
Max. gradeability 42%
Approach angle 11°
Departure angle 12°
Min. ground clearance 234mm
