XCMG QAY800 Used All Terrain Cranes Second Hand 800 Ton Mobile Crane

Place of Origin China
Brand Name XCMG
Certification CE , ISO9001
Model Number QAY800
Minimum Order Quantity 1
Price Negotiable
Packaging Details Bulk
Delivery Time 5-7 Days
Payment Terms L/C, T/T

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

Product Details
Condition Used Maximum Lifting Height 18.4- 105.3m
Maximum Lifting Weight 800 Ton Axle Number 8
Jib 2 Section  production Date 2013
High Light

XCMG QAY800 Used All Terrain Cranes


105.3m Used All Terrain Cranes


Second Hand 800 Ton Mobile Crane

Leave a Message
Product Description

XCMG Used All-Terrain Truck Crane XCMG QAY800 Ton Second Hand Crane
Production Details:

Model NO.


Boom Type Telescopic

Max. Rated Lifting Capacity

800000 kg Max. Lifting Height of Jib 84m

Max Gradeability

40% Working Diameter 29m

Transport Package

Compliant with export packaging requirements Specification


Driving Mileage


Working hours



XCMG Place of Origin China

HS Code

  Supply Capacity 1 Units Per Month


  • XCMG QAY800 all-terrain cranes are positioned for 1.5-2MW wind power installation and maintenance, petrochemical equipment hoisting and bridge construction.
  • The whole vehicle adopts 8-axle all-ground special chassis, 4-axle drive, X-type outrigger structure; seven-section U-section box-type main boom, the boom length is 16.8m ~ 84m, the new truss boom system design, fixed jib: boom length 14.5m ~ 56.5m, luffing jib: standard 21m ~ 63m.
  • Dual working mode operation mode, equipped with double-rate Y-type superlift, with core technologies such as rapid self-disassembly, multi-mode steering, multi-brake comprehensive management, etc., to ensure efficient and safe operation.
  • A variety of boom combinations, suitable for a variety of working conditions, equipped with double working conditions boom technology and special wind power boom technology, for (2.0-2.5) MW wind power hoisting, strong adaptability, superior performance, simple operation, installation and transportation convenient;
  • Adopt wireless and touch screen display intelligent control technology, full working condition fault diagnosis technology, rich functions, safe and convenient operation;
  • The new boom design, the third bracket of the luffing pair, and the airfoil connection frame design, the boom safety is high and the boom stability is good;
  • Self-disassembly and assembly of the boom, rope-type hanging counterweight technology, a model of humanized design, convenient and efficient disassembly and assembly;
  • Multi-axle heavy-duty off-road chassis technology, comprehensive management of braking system, all-wheel steering, safe braking, strong power, excellent driving performance, stronger climbing ability, and higher efficiency of heavy-duty transition.

Product Parameters:

Item Unit Parameters
Parameters item   QAY800
Overall length of the whole machine mm 19420
Overall width of the whole machine mm 3000
Overall height of the whole machine mm 4000
Wheelbase mm



Tire distance mm 2590
Total mass in driving state kg 93900
Axle load kg 12000×5+11300×3
Dynamic parameters
Engine model (Operating cab)   OM460LA.E3A
Engine rated power kw/(r/min) 260/1800
Engine rated torque N.m/(r/min) 1750/1300
Engine model (Driving cab)   OM502LA.E3A/1
Engine rated power kw/(r/min) OM502LA.E3A/1
Engine rated torque N.m/(r/min) 2800/1300
Traveling parameters
Top speed km/h 75
Min. stable driving speed km/h 2.4
Min. turning diameter m 29
Boom head Min. turning diameter m -
Max. gradeability 40
Min. ground clearance mm 280
Approach angle ° 12
Departure angle ° 28
Braking distance m ≤10
Oil consumption per 100 km L 110
Main performance parameters
Max. gradeability (%) -
Max. rated lifting capacity t 800
Min. rated amplitude m 3
Max. lifting moment of the basic boom kN·m 24000
Turntable tail turning radius mm 10640
Vertical m 12.8(10.7)
Horizontal m 13(9.8)
Max. lift height
Basic boom m 18.4
Longest main boom m 85.8
Longest main boom + jib m 105.3
Boom length
Basic boom m 16.8
Longest main boom m 84
Longest main boom + jib m -
The longest main boom + jib + extension m 63
Working speed
Max. rotation speed r/min 0.6
Lifting speed
Main hoisting mechanism (m/min) 110 (outermost working layer)
Auxiliary lifting mechanism (m/min) 110 (outermost working layer)
Luffing jib luffing winch (m/min) 65 (fourth floor)
Boom extension time
Full extension (s) 1200
Full retraction (s) 1100
Amplitude time
Full boom lift s 115
Full boom drop s -
Outrigger retractable
put at the same time s 35
receive at the same time s 35
put at the same time s 75
receive at the same time s 75
