XCMG QAY650 Used All Terrain Cranes 650 Ton Mobile Crane 152m

  • XCMG QAY650 Used All Terrain Cranes 650 Ton Mobile Crane 152m
  • XCMG QAY650 Used All Terrain Cranes 650 Ton Mobile Crane 152m
Place of Origin China
Brand Name XCMG
Certification CE , ISO7501
Model Number QAY650
Minimum Order Quantity 1
Price Negotiable
Packaging Details Bulk
Delivery Time 5-7 Days
Payment Terms L/C, T/T

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Status Used Max. Lifting Height 18- 152m
Ma. Lifting Weight 650 Ton Axle No. 8
Jib Boom 2 Section Production Date 2014
High Light

152m Used All Terrain Cranes

,

QAY650 Used All Terrain Cranes

,

650 Ton Mobile Crane
Leave a Message
Product Description

Used XCMG All- Terrain Truck Crane XCMG QAY650 Ton Second Hand Crane



Production Details:



Model NO.



QAY650

 Boom Type Telescopic



Max. Rated Lifting Capacity



 650000 kg Max. Lifting Height of Jib 92m



Max. Gradeability



 40% Turning Diameter 29m



Transport Package



 Compliant with export packaging requirements Specification

22695×3000×4000mm



Drive Mileage



 60000ms Working hours 4000h



Trademark



 XCMG Place of Origin China



  • XCMG QAY650A all-terrain crane is positioned to meet the mainstream 1.5MW wind turbine installation requirements in the market, and can meet the construction and maintenance of some 2.0MW wind power, petrochemical equipment hoisting and bridge construction.
  • Adopts 8 axles all-terrain special chassis, the driving and steering form is 16×8×16, X-type outrigger structure; 7-section U-section box-type main boom, the boom length is 18-92meters; equipped with double-rate Y-type super lifting, luffing jib and special wind power boom head, the longest fixed jib can be up to 56meters, and the luffing jib can be up to 56m.
  • Special wind power boom head working condition design to meet the installation requirements of 2.0MW wind turbines;
  • The new self-top counterweight hooking method is adopted to realize the self-disassembly of the counterweight.
  • Using black box technology, touch screen display control technology, fault detection, diagnosis technology and many other high-tech technologies.
  • The chassis power system is optimized and matched, that is more efficient and energy-saving; the precise electronically controlled multi-mode steering system ensures flexible and reliable steering; the advanced multi-brake integrated management system ensures safe and economical driving.



Product Parameters:

Item



Unit



Value


Parameters items   QAY650

Dimensions


Overall length of the whole machine mm 22695
Overall width of the whole machine mm 3000
Overall height of the whole machine mm 4000
Wheelbase mm

1500+2150+1500+1500

+3430+3680+1500
Tire distance mm 2590

Weights


Total mass in driving state kg 94400
Axle load kg 11680×5+12000×3

Dynamic parameters


Engine model (Operating cab)   OM906LA
Engine rated power kw/(r/min) 205/2100
Engine rated torque N.m/(r/min) 1110/1200～1600
Engine model (Driving cab)   OM502LA.E3A/1
Engine rated power kw/(r/min) 480/1800
Engine rated torque N.m/(r/min) 2800/1300

Traveling parameters



Traveling
Top speed km/h 75
Min. stable driving speed km/h 2

Turn
Min. turning diameter m 29
Boom head Min. turning diameter m 34
Max. grade ％ 40(94.4t)
Min. ground clearance mm 280
Approach angle ° 12
Departure angle ° 30
Braking distance m ≤10
Fuel consumption per 100 km L 110

Main performance parameters


Max. grade (％) -
Max. Rated Gross Lifting Weight t 650
Min. rated amplitude m 3
Max. lifting moment of the basic arm kN·m 19500
Turntable tail turning radius mm 7300 (balance weight)

Outrigger


Vertical m 11.1
Horizontal m 10
Max. lift height
Basic boom m 19
Longest main arm m 91
Longest main boom + jib m 130
Boom length
Basic boom m 18
Longest main arm m 92
Longest main boom + jib m -
The longest main boom + jib + extension m 56/91(optional)
Working speeds
Max. rotation speed r/min 1
Lifting speed
Main hoisting mechanism (m/min) 140(empty)
Auxiliary hoisting mechanism (m/min) -
Luffing jib luffing winch (m/min) 140

Boom extension time


Fully extension (s) 1350
Fully contraction (s) 1350

Amplitude time


Full boom lift s 150
Full boom drop s -

Outrigger retractable


Horizontal
put at the same time s -
receive at the same time s -
Vertical
put at the same time s -
receive at the same time s -
