Used Sany Crawler Crane 150 Ton SCC1500C Second Hand Crawler Crane

Place of Origin China
Brand Name Sany
Certification CE, ISO9001
Model Number SCC1500C
Minimum Order Quantity 1
Price Negotiable
Packaging Details Bulk
Delivery Time 5-7 Days
Payment Terms L/C, T/T

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Condition Used Maximum Lifting Height 81~31 M
Maximum Lifting Weight 150 Ton Jib 3 Section
Specification 12300×3360×3300mm  production Date 2010
High Light

sany crane 150 ton

,

sany crawler crane 150 ton

,

Sany Crawler Crane SCC1500C

Leave a Message
Product Description

Used Sany Crawler Crane Sany SCC1500C Second Hand Crawler Crane



Production Details:



Model NO.



SCC1500C Boom Type Tower boom



Max. Rated Lifting Capacity



150000 kg Max. Lifting Height of Jib 81m



Max Gradeability



30% Working hours 15534.3h



Transport Package



Compliant with export packaging requirements Specification 12.7×3.4×3.4 M



Trademark



Sany Place of Origin China



HS Code



  Supply Capacity 10 Units Per Month



1.Optimized design for transport and assembly/disassembly

* The basic machine is designed for integrated transportation, and there is no need to disassemble the crawler frame and the boom base, which greatly saves transportation costs and improves assembly/disassembly efficiency.

* The unique A-type gantry self-supporting technology can realize self-supporting without oil cylinder and realize the rapid assembly of the crane.

* The weight of a single counterweight does not exceed 4 tons, and a small auxiliary lifting device can achieve a complete counterweight assembly.


2. Optimized hydraulic system design

* All-in-one design reduces failure points while reserving open space for assembly/disassembly and maintenance. * Adopt highly integrated LUDV main valve, with multi-way operation, control combined flow, high/low speed selection and other functions to ensure operation efficiency.

* The unique independent bypass filter and strong magnetic adsorption device in the industry are used to strengthen the filtering and anti-emulsification ability of the hydraulic system. 3. One-key switching function of main/auxiliary hooks Using a one-key switch, the main/auxiliary hook switching can be easily realized, and the application range is wider.



This machine was manufactured in 2010. The main boom length is 81m, jib length is 31m, the main hook is 50T, the auxiliary hook is 15T, no quick release, no overfitting, and the vehicle condition is very good.



Product Parameters:

Main boom condition



Max. lifting weight 155t
Max. Lifting Moment 124.5×7t•m
Boom length 18~81m
Main boom luffing 30°~80°

Fixed jib condition



Max. Lifting Moment 11.5×35.3t•m
Boom length 27~75m
Jib length 13~31m
Longest main boom + longest fixed jib 69+31/75+13m
Main boom luffing 30°~80°
Jib variable angle 15°,30°

Working condition of luffing jib



Max. Lifting Moment 14.8×22t•m
Boom length 34.79~49.79m
Luffing Jib Length 27~45m
Longest main boom + longest luffing jib (49.8+45)m
Jib variable angle 25°~72°

Speed parameter



Main winch rope speed 0~125m/min
Auxiliary winch rope speed 0~125m/min
Luffing winch rope speed (0~24)×2 m/min
Swing speed 0~2.0rpm
Driving speed

1.2/0.6 km/h

(Double-speed)

Gradeability 30%

Engine



Output Power 242kW
Rated speed 2100rpm

Weight



Total Weight 153.2t
counterweight 53.2t
Max. single piece shipping weight 53.6t
Shipping Dimensions (L×W×H) 16990×3470×3500mm
Ground specific pressure (basic arm) 0.093MPa
Note: Main/auxiliary hoist rope speed, luffing hoist rope speed, rotation and travel speed vary according to the size of the load.
The speed of the main and auxiliary hoisting ropes refers to the speed of the third working layer.
The speed of the luffing hoisting rope refers to the speed of the fifth working layer.
