75 Ton Used Crawler Cranes XCMG XGC75 Second Hand Crawler Crane MOY 2017

Place of Origin China
Brand Name XCMG
Certification CE, ISO9001
Model Number XGC75
Minimum Order Quantity 1
Price Negotiable
Packaging Details Bulk
Delivery Time 5-7 Days
Payment Terms L/C, T/T

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Condition Used Maximum Lifting Height 13~58 M
Maximum Lifting Weight 75 Ton Jib 2 Section
Specification 12.7×3.4×3.4 M  production Date 2017
High Light

75 Ton Used Crawler Cranes

,

XGC75 Used Crawler Cranes

,

2017 XCMG Crawler Cranes

Leave a Message
Product Description

Used Crawler Crane XCMG XGC75 Second Hand Crawler Crane MOY 2010

Production Details:


Model NO.


XGC75

Boom Type Tower boom


Max. Rated Lifting Capacity


75000 kg Max. Lifting Height of Jib 49m


Max Gradeability


30% Working hours 6000H


Transport Package


Compliant with export packaging requirements Specification

12.7×3.4×3.4 M


Trademark


XCMG Place of Origin China


HS Code


  Supply Capacity 1 Units Per Month



1. Optimized design of transportation and assembly/disassembly

* The basic machine is designed for integrated transportation, without disassembling the crawler frame and boom base, which greatly saves transportation costs and improves assembly/disassembly efficiency.

* The unique A-type gantry self-supporting technology can realize self-supporting without oil cylinder and realize the rapid assembly of the crane.

* The weight of a single counterweight does not exceed 4 tons, and a small auxiliary lifting device can achieve a complete counterweight assembly.



2. Optimized hydraulic system design

* Integrated design reduces failure points while reserving open space for assembly/disassembly and maintenance.

* Adopt highly integrated LUDV main valve, with multi-way operation, control combined flow, high/low speed selection and other functions to ensure operation efficiency.

* The unique independent bypass filter and strong magnetic adsorption device in the industry are used to strengthen the filtering and anti-emulsification ability of the hydraulic system.



3.  One-key switching function of main/auxiliary hooks Using a one-key switch

 the main/auxiliary hook switching can be easily realized, and the application range is wider.



Product Parameters:

Item Unit Parameters
Parameter item - XGC75
Working performance parameters
Max. rated lifting capacity of main boom (t) 75
Max. rated lifting capacity of fixed jib (t) 12
Max. rated lifting capacity of luffing jib (t) -
Max. Lifting Moment (t.m) 286
Max. lifting capacity of tower jib (t) -
Max. rated lifting capacity of single pulley at arm end (t) 6.5
Max. rated lifting capacity of dedicated jib (t) -
Size parameters
Boom length (m) 13~58
Main boom luffing angle (°) -3~80
Fixed jib length (m) 7~19
Tower jib length (m) -

Max. size of a single piece in shipping state

(length × width × height)

(m) 12.7×3.4×3.4
Fixed jib mounting angle (°) 10°,30°
Dedicated Jib Length (m) -
Speed parameters
Max. single rope speed of hoisting mechanism (m/min) 128
Max. single rope speed of main boom luffing mechanism (m/min) 70
Max. single rope speed of jib luffing mechanism (m/min) -
Max. rotation speed (r/min) 3
Top speed (km/h) 1.4
Gradeability (%) 30
Average ground pressure (MPa) 0.08
Max. single rope speed of tower boom luffing mechanism (m/min) -
Super hoisting and luffing Max. single rope speed (m/min) -
Engine
Model - SC7H210/QSB6.7
Engine power (kW) 154/153
Emission - National II/Euro III
Weights
Machine weight (t) 61(Main hook, 13m jib)
Max. mass per piece in shipping condition (t) 37
