XCMG XCT75 Used Truck Cranes 75ton Boom Truck Cranes For Sale

  • XCMG XCT75 Used Truck Cranes 75ton Boom Truck Cranes For Sale
  • XCMG XCT75 Used Truck Cranes 75ton Boom Truck Cranes For Sale
Place of Origin China
Brand Name XCMG
Certification CE, ISO9001
Model Number XCT75
Minimum Order Quantity 1
Price Negotiable
Packaging Details Bulk
Delivery Time 5-7 Days
Payment Terms L/C, T/T
Supply Ability 10PCS/M

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Condition Used Maximum Lifting Height 12.4- 74m
Maximum Lifting Weight 75ton Axle Number 4
Jib 2 Section  production Date 2018
High Light

XCT75 Used Truck Cranes

,

75ton Used Truck Cranes

,

used boom truck cranes for sale
Leave a Message
Product Description

Used Truck Crane XCMG XCT75 Second Hand Truck Mobile Crane



Production Details:



Model No.



XCT75

 Boom Type Telescopic



Max. Rated Lifting Capacity



 75000 kg Max. Lifting Height of Jib 48m



Max Gradeability



 45% Working Diameter 24m



Transport Package



 Complies with Min. export packaging requirements Specification

14700×2750×3910mm



Driving Mileage



 400000M Working hours 3200h



Trademark



 XCMG Place of Origin China



HS Code



   Supply Capacity 10 Units/ Month



XCMG XCT 75-ton truck crane, K-type outrigger, compact structure, leading performance, safe and reliable, economical and environmentally friendly, is a high-quality model tailored for users.

  • The overall lifting performance of the 75-80-ton products leads the industry, and the lifting performance of the whole machine is more than 20% higher than that of the products of the same tonnage in the industry;
  • Low-speed high-torque power system, strong power, strong off-road capability and low fuel consumption. Fuel consumption is reduced by 12%, and gradeability is improved by 15%;
  • New energy-saving hydraulic system, dual-pump split and confluence, fast speed and good compound action. The average fuel consumption under comprehensive working conditions is reduced by 8%, and the ride comfort and fretting performance are improved by 15%;
  • The new human-computer interaction system makes driving more comfortable;
  • A new generation of appearance, humanized design, user operation is more comfortable and convenient;



Product Parameters:

Parameter item XCT75
Dimensions *
Overall length of the whole machine (mm) 14700
Overall width of the whole machine (mm) 2750
Overall height of the whole machine (mm) 3910
Wheelbase(mm) 1470+3950+1350
Tire distance(mm) 2316/2063
Weight parameter *
Total mass in driving state (kg) 46000
Axle load(kg) 10000×2+13000×2
Dynamic parameters *
Engine model MC11.36-40SC10E360Q4
Engine rated power (kw/(r/min)) 268/1900 265/1900
Engine rated torque (N.m/(r/min)) 1800/1000-14001700/1300
Traveling parameters *
Traveling *
Max. travel speed (km/h) 90
Min. stable driving speed (km/h) 2.5～3
Turning *
Min. turning diameter (m) 24
Arm head Min. turning diameter (m) 28.8
Max. grade(%) 45
Min. ground clearance (mm) 305
Approach angle (°) 16
Departure angle (°) 13.5
Braking distance (m) ≤10
Fuel consumption per 100 kilometers (L) 40
Main performance parameters *
Max. rated total lifting weight (t) 75
Min. rated amplitude (m) 3
The Max. lifting moment of the basic arm (kN m) 3175
Turntable tail turning radius (mm) 4545
Outrigger *
Longitudinal (m) 8.45
Horizontal (m) 7.9(5.6)
Max. lift height *
Basic arm (m) 12.7
The longest main boom (m) 48
The longest main boom + jib (m) 65
The longest main boom + jib + extension 74
Boom length *
Basic arm (m) 12.4
Longest main boom (m) 48
Longest main boom + jib 65.5
The longest main boom + jib + extension section (m) 74.5
Working speed *
Max. rotation speed (r/min) 2
Lifting speed *
Main hoisting mechanism 145
Auxiliary lifting mechanism 90
Boom extension time *
Full extension(s) 110
Full shrink -
Amplitude time *
Full lift (s) 55
Full arm drop(s) -
Outrigger retraction--horizontal *
Simultaneously put -- horizontal (s) 50
At the same time closing -- horizontal (s) 40
Outrigger retraction-vertical *
Simultaneously put(s) 50
Simultaneous receipt (s) 45

XCMG XCT75 Used Truck Cranes 75ton Boom Truck Cranes For Sale 0XCMG XCT75 Used Truck Cranes 75ton Boom Truck Cranes For Sale 1
