XCT55L6 Used XCMG Truck Crane 55 Ton Second Hand Truck Mobile Crane

Place of Origin China
Brand Name XCMG
Certification CE, ISO9001
Model Number XCT55L6
Minimum Order Quantity 1
Price Negotiable
Packaging Details Bulk
Delivery Time 5-7 Days
Payment Terms L/C, T/T
Supply Ability 10PCS/M

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

Product Details
Condition Used Maximum Lifting Height 10.6- 66m
Maximum Lifting Weight 55ton Axle Number 4
Jib 2 Section  production Date 2017
High Light

Used XCMG Truck Crane


Second Hand XCMG Truck Crane


xcmg 55 ton crane

Leave a Message
Product Description

Used Truck Crane XCMG XCT55L6 Second Hand Truck Mobile Crane


Production Details:


Model No.



Boom Type Telescopic


Max. Rated Lifting Capacity


260000 kg Max. Lifting Height of Jib 50m


Max Gradeability


45% Working Diameter 24m


Transport Package


Complies with Min. export packaging requirements Specification



Driving Mileage


560000M Working hours 6200h




XCMG Place of Origin China


HS Code


  Supply Capacity 10 Units/ Month


  • Standard reshaping, all-round leadership, the industry's first product with a 6-section boom and a 50-meter boom has established a new height in the industry.
  • The original new single-cylinder latch system realizes six booms, the boom length reaches 50m, and the lifting performance leads the industry by more than 20%.
  • Low-speed high-torque power system to achieve the perfect combination of optimal power and optimal economy. The Max. climbing ability is 45%, the Max. driving speed is 90km/h, the highest in the industry, and the fuel consumption per 100 kilometers is 35L.
  • The new electric proportional pump-controlled energy-saving hydraulic system has lower operating fuel consumption and better fretting performance. The average fuel consumption under comprehensive operating conditions is 15% lower than that of peers, and the fretting and smoothness are improved by 20%, enabling precise hoisting.
  • The intelligent boom technology realizes automatic planning of working conditions, hoist follow-up, and amplitude compensation, and the level of intelligence is leading in the world.
  • The XCMG-machine interaction system reaches the car-level level, providing a comfortable and intelligent operating experience. XCMG G generation has a new appearance and humanized design, making the operation more comfortable and convenient.


Product Parameters:

parameter item XCT55L6
Dimensions *
Overall length of the whole machine (mm) 13650
Overall width of the whole machine (mm) 2540
Overall height of the whole machine (mm) 3770
Wheelbase(mm) 1470+3700+1350
Tire distance(mm) 2124/2124/1834/1834
Weight parameter *
Deadweight in traveling condition (kg) 44000
Axle load(kg) 9000+9000+13000×2
Dynamic parameters *
Engine model MC11.36-40,SC10E340Q4
Engine rated power (kw/(r/min)) 268/1900,251/1900
Engine rated torque (N.m/(r/min)) 1800/1000-1400,1550/1300
Traveling parameters *
Traveling *
Max. travel speed (km/h) 90
Min. stable driving speed (km/h) 2.5~3
Turning *
Min. turning diameter (m) 24
Boom head Min. turning diameter (m) 26.2
Max. gradeability(%) 45
Min. ground clearance (mm) 303.5
Approach angle (°)

16 (including front protection 10°)

Departure angle (°) 13
Braking distance (m) ≤10
Fuel consumption per 100 kilometers (L) 35
Main performance parameters *
Max. rated lifting capacity (t) 55
Min. rated amplitude (m) 3
Max. load moment of the basic boom (kN m) 2058
Turntable tail turning radius (mm) 3830
Outrigger *
Longitudinal (m) 8.035
Horizontal (m) 7.3
Max. lift height *
Basic boom (m) 10.7
The longest main boom (m) 49.1
The longest main boom + jib (m) 63.8
The longest main boom + jib + extension -
Boom length *
Basic boom (m) 11.2
Longest main boom (m) 50
Longest main boom + jib 66
The longest main boom + jib + extension section (m) -
Working speed *
Max. slewing speed (r/min) 2
Lifting speed *
Main hoisting mechanism 130
Auxiliary lifting mechanism 130
Boom extension time *
Full extension(s) 350
Full shrink -
Amplitude time *
Full lift (s) 50
Full boom drop(s) -
Outrigger retraction--horizontal *
Simultaneously put -- horizontal(s) 30
At the same time closing -- horizontal (s) 20
Outrigger retraction-vertical *
Simultaneously put(s) 30
Simultaneous receipt (s) 20
