Used Zoomlion Truck Crane Zoomlion QY80V Second Hand Truck Mobile Crane

  • Used Zoomlion Truck Crane Zoomlion QY80V Second Hand Truck Mobile Crane
  • Used Zoomlion Truck Crane Zoomlion QY80V Second Hand Truck Mobile Crane
  • Used Zoomlion Truck Crane Zoomlion QY80V Second Hand Truck Mobile Crane
Place of Origin China
Brand Name Zoomlion
Certification CE, ISO9001
Model Number QY80V
Minimum Order Quantity 1
Price Negotiable
Packaging Details Bulk
Delivery Time 5-7 Days
Payment Terms L/C, T/T

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Condition Used Maximum Lifting Height 13.8 - 75m
Maximum Lifting Weight 80ton Axle Number 4
Jib 2 Section  production Date 2012
Leave a Message
Product Description

Used Zoomlion Truck Crane Zoomlion QY80V Second Hand Truck Mobile Crane

Production Details:


Model No.


QY80V

 Boom Type Telescopic


Max. Rated Lifting Capacity


 80000 kg Max. Lifting Height of Jib

48.8m


Max Gradeability


 40% Working Diameter 24m


Transport Package


 Complies with Min. export packaging requirements Specification

15000 × 2850 × 3850MM


Driving Mileage


 800000M Working hours 7000h


Trademark


 Zoomlion Place of Origin China


HS Code


   Supply Capacity

10 Units/ Month




  • This product is a full-slewing, telescopic boom type, hydraulic proportional control truck crane. It adopts the company's self-made full-drive four-axle special chassis, with wide field of vision, luxurious and comfortable decoration, 8×4 drive, hydraulic power steering, light weight flexible.



Product Parameters:

Item



QY80V


Working performance Max. rated lifting capacity (kg) 80000
Max. load moment of basic boom (kN.m) 3116
Max. load moment of Max. length boom (kN.m) 1646
Max. lifting height of basic boom (m) 13.7
Max. lifting height of main boom (m) 48.8
Max. lifting height of jib (m) 66.0
Max. lifting height of jib (m) 75.0

Working speeds

 Max. hoist rope speed (main winch) (m/min) 130
Max. hoist ropes peed (auxiliary winch) (m/min) 110
Boom derricking up time (min) 62
Boom telescoping out time (s) 145
Max. slewing speed (r/min) 0-1.6
Traveling parameters Max. traveling speed (km/h) 75
Max. gradeability (%) 40
Min. turning diameter (m) ≤24
Min. ground clearance (mm) 280
Oil consumption per 100 km (L) 46

Weights

 Deadweight in traveling condition(kg) 50000
Complete vehicle kerb mass(kg) 49870
Front axle load (kg) 24000
Rear axle load (kg) 26000
Dimensions Dimensions (L×W×H) (mm) 15000×2850×3850
Longitudinal distance between outriggers (m) 6.38
Transversal distance between outriggers (m)

Full extension 8.0,

Half extension 5.28
Tail turning radius (mm) 4390
Main boom length (m) 12.5—48.0
Main boom elevation angle (°) -2- 80
Extended arm length (optional) (m) 9.0
Extension arm mounting angle (°) 0
Jib length (m) 10.3,17.5
Offset (°) 0,15,30
