QY25V Zoomlion Used Truck Cranes 25 Ton 2nd Hand Crane

  • QY25V Zoomlion Used Truck Cranes 25 Ton 2nd Hand Crane
  • QY25V Zoomlion Used Truck Cranes 25 Ton 2nd Hand Crane
Place of Origin China
Brand Name Zoomlion
Certification CE, ISO9001
Model Number QY25V
Minimum Order Quantity 1
Price Negotiable
Packaging Details Bulk
Delivery Time 5-7 Days
Payment Terms L/C, T/T

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Status Used Max. Lifting Height 11 - 47m
Max. Lifting Weight 25ton Axle No. 3
Jib Boom 2 Section Production Date 2010
Highlight

QY25V Used Truck Cranes

,

25 Ton Used Truck Cranes

,

Zoomlion 2nd Hand Crane
Leave a Message
Product Description

Used Zoomlion Truck Crane Zoomlion QY25V Second Hand Truck Mobile Crane

Production Details:


Model No.


QY25V

 Boom Type Telescopic


Max. Rated Lifting Capacity


 25000 kg Max. Lifting Height of Jib 39m


Max Gradeability


 35% Working Diameter 24m


Transport Package


 Complies with Min. export packaging requirements Specification

12700x2500x3450MM


Driving Mileage


 800000M Working hours 7000h


Trademark


 Zoomlion Place of Origin China


HS Code


   Supply Capacity

10 Units/ Month






This machine is a full-slewing, telescopic boom type, hydraulic proportional control five-section boom truck crane. The chassis uses the company's self-made full-drive three-axle special chassis, which is discharged from Guochuan and has a wide field of vision.



This product adopts the latest hydraulic proportional reversing valve with load feedback and quadruple gear pump system. Used with relief valve, balance valve, hydraulic lock, brake valve and other safety devices.



It is equipped with many of safety devices such as torque limiters and a complete lighting system, that can ensure the safety and reliability of the work and facilitate night work.



The truck's exhaust emissions comply with Euro III, and its safety devices meet the requirements of 3C certification.



This product was manufactured in October 2010, with five-section boom, jib, two hooks, and excellent performance. It is a very widely used model.


Product Parameters:

Item Value Remarks
Working performance Max. rated lifting capacity (kg) 25000
Max. load moment of basic boom (kN.m) 980
Max. load moment of the longest main boom (kN.m) 494
Max. lifting height of basic boom (m) 11.0
Max. lifting height of main boom (m) 39

Boom deformation is not considered
Max. lifting height of jib (m) 47.0
Working speeds Max. hoist rope speed (main winch) (m/min) 120 At fourth layer
Max. hoist ropes peed (auxiliary winch) (m/min) 170 At second layer
Boom derricking up time (s) 40
Boom telescoping out time (s) 80
Max. rotation speed (r/min) 0～2.2
Driving parameters Max. travel speed (km/h) 78
Max. gradeability (%) 37
Min. turning diameter (m) 22
Min. ground clearance (mm) 220
Limits for exhaust pollutants and smoke Conform to related standards GB3847-2005 GB17691-2005 Phase III
Oil consumption per 100 km (L) 45
Weight parameters Deadweight in traveling condition (kg) 31700
Complete vehicle kerb mass (kg) 31570
Front axle load (kg) 6900
Rear axle load (kg) 24800
Dimensions Dimensions (L×W×H) (mm) 12700x2500x3450
Longitudinal distance of outriggers (m) 5.36
Outrigger lateral distance (m) 6.1
Main boom length (m) 10.4~39.2
Main boom elevation angle (°) -2～80
Jib length (m) 8
Offset ( °) 0 , 30
Chassis Model zlj5325
Type Class II
Engine   Model WP10.375N
Rated power (kW/r/min) 199/2200
Max. output torque (N.m/r/min) 1100/1300~1600



QY25V Zoomlion Used Truck Cranes 25 Ton 2nd Hand Crane 0QY25V Zoomlion Used Truck Cranes 25 Ton 2nd Hand Crane 1
