90ton Used Truck Crane Zoomlion ZLJ5551JQZ90V Second Hand Truck Mobile Crane

  • 90ton Used Truck Crane Zoomlion ZLJ5551JQZ90V Second Hand Truck Mobile Crane
  • 90ton Used Truck Crane Zoomlion ZLJ5551JQZ90V Second Hand Truck Mobile Crane
  • 90ton Used Truck Crane Zoomlion ZLJ5551JQZ90V Second Hand Truck Mobile Crane
Place of Origin China
Brand Name Zoomlion
Certification CE, ISO9001
Model Number ZLJ5551JQZ90V
Minimum Order Quantity 1
Price Negotiable
Packaging Details Bulk
Delivery Time 5-7 Days
Payment Terms L/C, T/T

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Condition Used Maximum Lifting Height 42.1 - 58.3m
Maximum Lifting Weight 90ton Axle Number 5
Jib NO  production Date 2012
High Light

Second Hand Truck Crane Zoomlion

,

90ton Truck Crane Zoomlion

,

ZLJ5551JQZ90V
Leave a Message
Product Description

Used Zoomlion Truck Crane Zoomlion ZLJ5551JQZ90V Second Hand Truck Mobile Crane



Production Details:



Model NO.



 ZLJ5551JQZ90V Boom Type Telescopic



Max. Rated Lifting Capacity



 90000 kg Max. Lifting Height of Jib 56.5m



Max Gradeability



 43% Working Diameter 24m



Transport Package



 Complies with Min export packaging requirements 规格 Specification 14690×2800×3800mm



Driving mileage



 10000km Working hours 80000h



Trademark



 Zoomlion Place of Origin China



HS Code



   Supply Capacity 10 Units Per Month



Zoomlion ZLJ5551JQZ90V truck crane is a new generation of high-performance product independently developed by our company in order to meet the market demand and integrate many years of experience and advanced technology. The performance parameters such as lifting height, main boom length, working speed and lifting capacity of the crane are all at the current international advanced level.

This product is a full-slewing, telescopic boom type, electro-hydraulic proportional control truck crane. The upper truck is powered by an independent engine, and the chassis adopts the company's self-made full-drive five-axle special chassis. It has a wide field of vision and luxurious and comfortable decoration. 10 ×6 drive, hydraulic power steering, light and flexible.

This product adopts the latest electro-hydraulic proportional reversing valve with load feedback and triple pump system, which makes the working ability of each actuator fully exerted. Double rocker operation can realize the main and auxiliary lifting, luffing, slewing, and telescoping. The combined action between the mechanisms greatly improves the working efficiency of the crane. It has the characteristics of light and flexible operation, stable and reliable work, stepless speed regulation and so on. In the hydraulic system, there are safety devices such as relief valve, balance valve, hydraulic lock, brake valve, etc., to prevent the overload of the oil circuit and avoid accidents caused by the rupture of the oil pipe. The crane is equipped with a variety of safety devices such as torque limiters and a complete lighting system, which can ensure safe and reliable operation and facilitate night operations.

The product is novel in shape, and integrates beauty in shape, shape and color.



Product Parameters:

Item Value Remarks
Working performance Max. rated gross lifting capacity (kg) 90000
Max. load moment of the basic boom (kN.m) 3300
Max. load moment of the longest main boom (kN.m) 1800
Max. lifting height of the basic boom (m) 13.4
Max. lifting height of main boom (m) 56.5

Boom deformation is not considered
Max. lifting height of jib (m) 75/(80.5)
Working speeds Max. hoist ropes peed (main winch) (m/min) 122 Reel fourth layer
Max. hoist ropes peed (auxiliary winch) (m/min) 68 reel second layer
Boom derricking up time (s) 72
Boom telescoping out time (s) 800
Max. slewing speed (r/min) 1.5
Traveling parameters Max. travel speed (km/h) 78
Max. gradeability (%) 43
Min. turning diameter (m) 24
Min. ground clearance (mm) 280
Limits for exhaust pollutants and smoke Conform to related standards GB3847-2005 GB17691-2005 Phase III
Oil consumption per 100 km (L) 70
Weight parameters Deadweight in traveling condition (kg) 54600
Complete vehicle kerb mass(kg) 54405
Front axle load (kg) 19200
Rear axle axle load (kg) 35400
Dimensions Dimensions (L×W×H) (mm) 14690×2800×3800
Longitudinal distance of outriggers (m) 7.3
Outrigger lateral distance (m) 7.4
Main boom length (m) 12.5~56
Main boom elevation angle (°) -2～82
Jib length (m) 10.5 ,18.5,24.5(optional) When adding a 24.5m jib, the jib installation angle is only 0°
Offset (°) 0 , 30
Chassis Model ZLJ5552 ZLJ5552V3.1 (feature number)
Type Class II
Engine Model WP12.430N
Rated power (kW/r/min) 316/1900
Max. output torque (N.m/r/min) 2060/1000~1400
